Swarm UAV System: A fleet flown as a single formation from one station: arm, launch, reshape in flight, task

Aerial Systems[SWARM]

A fleet flown as a single formation from one station: arm, launch, reshape in flight, task and recover together.

Aircraft per formation: Up to 50; Extensible
Standard formations: 8
Reshaping: Collision-free
Operators: One

Overview

One operator per aircraft does not scale. A swarm is useful only if the operator's workload stays flat as the fleet grows, which makes the control station the real product and the airframes interchangeable.

The station arms and launches the fleet, forms it into a chosen shape at a set altitude, and reshapes it in the air without any two aircraft contesting the same space. A destination is a single click for the whole formation. Payload release, return to launch and landing in formation are likewise fleet-wide commands, and any one aircraft can be taken under manual control without disturbing the rest.

System qualities

01 / 05

Formations that mean something

Line, column, wedge, echelon left and right, circle, grid, diamond and arrow: the shapes that are actually used, selectable in flight.

02 / 05

Reshapes without a collision

Slot assignment minimises total travel and the paths are deconflicted in space and time, with an altitude-layer fallback when the geometry is tight.

03 / 05

One destination, whole fleet

Click the map and the formation flies there as a rigid body, holding its shape on the way.

04 / 05

Manual override at any moment

A key press seizes the whole formation for direct control and pauses autonomous flight; a single aircraft can be flown on a transmitter while the rest continue.

05 / 05
